Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment

中国 Hebei KN Wire Mesh Co., Ltd. 認証
中国 Hebei KN Wire Mesh Co., Ltd. 認証
とても効果的な防御壁です.ジュリアのサービスは素晴らしかったです.彼女は製品と輸送に関連する多くの問題を解決するのに私を助けました.工場への旅行も非常に楽しかったです.

—— デイヴィッド

コーラが私の会社に来て 私の問題を現場で解決してくれたことに感謝しています

—— ガブリエル

受け取った商品は素晴らしく、工場で見た製品と一致しています。リサの対応も気持ちの良いものでした。

—— ランビル

とても良い購入体験でした。メロディーの販売サービスレベルは最高で、多くの問題を解決してくれました。

—— Aydan

時間通りに受け取られるプロダクト。製品品質はよいです。costumerサービスは非常に親切です。hassle freeトランザクション。次の時間を再度発注することを躊躇しません。

—— Ventas

質は信頼できます!時間通りに受け取られるThanks.Product。

—— Buena

すばらしい販売人!!!!!あなたと働くことはあらゆる質問題を非常に安心、心配しませんです。

—— ピーター

私はずっと非常に幸せな、信頼できる製造者長年にわたりです。

—— Sworld

とても良い協力体験です 良い製品が私のプロジェクトを よりスムーズに進めました

—— セオドア

オンラインです

Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment

Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment

大画像 :  Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment

商品の詳細:
起源の場所: 河北,中国
ブランド名: Hebei KN
証明: ISO CE
モデル番号: KN10x10x1.4 30kg
お支払配送条件:
最小注文数量: 1000 個
価格: USD90-100 each pc
パッケージの詳細: 木製パレット
受渡し時間: 30日間
支払条件: T/T,ウェスタン・ユニオン
供給の能力: 毎月10000 PC
詳細製品概要
製品名: 迅速な出荷 低可視性 MZP プータンカ 不明な障害物 フェンス タンク対策用ワイヤー ウクライナに充実したストック サイズ: 10×10×1.4 10×5×1 そして4
材料: 70# スチールワイヤ 線直径: 0.4-0.9mm
証明: ISO CE インストール: 供給ビデオ
MOQ: 1000 個
ハイライト:

Obstacle Barrier Anti Tank Barrier

,

Quick Production Anti Tank Barrier

Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka
Product Specifications
Attribute Value
Product name Fast Shipment Low Visibility MZP Putanka Inconspicuous Obstacle Fence Anti Tank Wire with Abundant Stock for Ukraine
Size 10x10x1.4, 10x5x1.4
Material 70# steel wire
Wire Diameter 0.4-0.9mm
Certification ISO CE
Installation Supply Video
MOQ 1000 PCS
Product Overview

The Low Visibility MZP Putanka Inconspicuous Obstacle Fence is a specialized security barrier designed to provide effective and discreet protection. It is ideal for various applications where a high level of security is required without drawing unnecessary attention.

Barely Noticeable Obstacle 10x10x1.4m

Barely noticeable obstacle 10x10x1.4m is designed to provide effective obstruction of movement and hinder the advancement of state border violators. It helps to create favorable conditions for blocking and detention of offenders by border patrols and reserves, as well as restricts the impact of animals and people on signaling and control equipment.

These products are available for purchase with a floor space of 100 m² and a set weight of up to 30 kg.

Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment 0 Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment 1
Key Features
  • Low Visibility Design: The fence is engineered to blend seamlessly with its surroundings, making it difficult to detect while still providing robust security.
  • High-Quality Materials: Constructed from durable materials, this fence is built to withstand harsh weather conditions and long-term use, ensuring reliability and longevity.
  • Customizable Options: Available in various configurations to meet specific requirements, including different heights, lengths, and installation methods.
Unique Selling Points
  • Fast Shipping: Our efficient logistics system ensures that your order is processed and shipped quickly.
  • Abundant Stock: As one of the largest manufacturers and exporters in China, we maintain substantial inventory for prompt fulfillment.
  • Leading Manufacturer: With years of experience and a reputation for excellence, we are the largest exporter of this type of fence in China.
  • Factory Visits Welcome: We invite you to visit our factory to see our production process firsthand.
Technical Details
Product name Anti-Tank Barrier Netting
Overall dimensions when folded 1200mm x 600mm x 120mm
The set including 40 steel rings and 40 metal stakes
Weight 30 KG each pc
Material Annealed steel wire 0.5-0.9mm
Production Process

The wire ring connection will form a four-layer space grid with a height of 1.4 meters, a length of 10 meters and a width of 10 meters. The kit consists of 40 connecting rings with a diameter of 0.8 mm annealing wire manufactured as standard GOST 3282-74 and 40 metal posts (25 cm long).

Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment 2
Installation Instructions
1
Secure the start of the 0.9 mm wire to one of the tubes at the start of a row.
2
Lay a row of ramps in the correct direction, then return in the opposite direction following the pattern of laying the ramps to close the row of ramps.
3
Rewind the start of the wire secured to the tube (secured by winding) onto the last turn of the closed ramp.
4
Do not cut the wire at the end of the row! Each row is braided with a single wire along all 20 layers!
Installation Steps
1
Stretch two rows of coils to their full length
2
Lay out each row outward
3
Two rows should make four
4
To fix the coil with nails, you need to fix it with a thick coil with nails
5
Hold on to the propeller and move the wire sufficiently as shown in the picture.
6
By this move and stretch the bottom it will shows thick lines, thin lines will extend upward, after fix the outermost layer of coils.
Important Note: It is impossible to put it back together after unraveling, so it is important to perform all the steps correctly. The thickest diameter wire should be at the bottom, the tangle fixed to the ground with staples every 1-2 meters.
Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment 3 Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment 4 Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment 5
Company Information

We established in 2013 as a professional manufacturer engaged in the research, development, production, sale and service of Wire Mesh Container. Located in Anping county hengshui city with convenient transportation access. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements.

Company Details
Does the company have an export certificate? Yes
Does the company already export to Ukraine? Yes
Number of employees 820
Year established 2018
Company revenue CNY 71,550,000
Export volume per year CNY 60,620,390
Packaging method Plastic film outside
Certifications CE ISO
Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment 6 Fast Delivery Low Visibility Obstacle Barrier Metal Wire Anti Tank Barrier MZP Putanka Quick Production Fast Shipment 7
Applications
  • Military and Defense: Ideal for securing military bases and sensitive areas.
  • Border Security: Effective in creating secure perimeters along borders.
  • Critical Infrastructure: Protects vital installations such as power plants and communication centers.
How to Place an Order Quickly

Contact Us:

Email: julia@knwiremesh.com

Phone: +86-17734082565 (Available from 9:00 AM to 9:00 PM GMT+8)

Provide Order Details:

  • Product Specifications: Height, length, color, and any other specific requirements
  • Quantity: The number of units you need
  • Shipping Address: The destination address for delivery
Production Capacity: Our production department has made all preparations. We expect to complete all goods ahead of schedule, with one container (800pc) completed per day. 10,000 pieces can be completed in approximately 4-5 months.
