| 材料: | 0.5mm,0.6mm,0.8mm,0.9mm 鋼鉄ワイヤ 強い | ワイヤの厚さ: | 0.5〜0.8mm |
|---|---|---|---|
| ブランド名: | HEBEI KN | 受渡し時間: | 40フィートコンテナあたり7日 |
| 表面処理: | オイル保護 防水紙 収縮フィルム | 製品名: | 低可視線,目に見えない線網,MZP,MPP |
| サイズ: | 10x10x1.1-1.4 または 10x5x1.1-1.4m | 種類: | もっとグランド |
| MOQ: | 100セット | キーワード: | 低可視性のワイヤ網,MZP,MPP |
| サンプル: | 入手可能 | パッケージ: | オイル保護,収縮フィルム |
| 重量: | 26～30kg | ||
| ハイライト: | MZP Tank Barrier,Low Visibility Tank Barrier,Putanka Tank Barrier |
||
| Attribute | Value |
|---|---|
| Material | 0.5mm, 0.6mm, 0.8mm, 0.9mm Steel Wire, Strong |
| Wire Thickness | 0.5 - 0.8 mm |
| Brand Name | HEBEI KN |
| Delivery Time | 7 days per 40ft Container |
| Surface Treatment | Oil Protection, Water proof paper, Shrink Film |
| Product Name | Low Visible Wire, Invisible Wire Mesh, MZP, MPP |
| SIZE | 10x10x1.1-1.4 or 10x5x1.1-1.4m |
| Type | More Grands |
| MOQ | 100 SET |
| Key Words | low-visibility wire mesh, MZP, MPP |
| Sample | Available |
| Package | oil protection, shrink film |
| Weight | 26-30kgs |
A low-visibility wire fence (tangle) is a serious obstacle for wheeled and tracked vehicles. When you need a barrier that does its job without announcing its presence, low visibility wire is the solution. Engineered with thin, high-tensile wires and advanced non-reflective coatings, this system keeps your perimeter secure while remaining virtually undetectable to the untrained eye.
Rings are woven from galvanized or non-galvanized high-carbon wire GOST 7372-79 with a diameter of 0.5; 0.6; 0.8 and 0.9 mm.
Ring garlands are interconnected by wire twists from annealed wire with a diameter of 0.5-0.6 mm (GOST 3282-74). Pegs for fastening, rings for them are made from low-carbon wire.
If a person attempts to pass through the territory, they become entangled in it. Without outside help, it is impossible to escape from the tangle. Therefore, the offender remains safely waiting for the guard on the spot.
When armored vehicles or tanks pass through, the machine wraps around the wheels and turns into a pile of metal on the chassis, preventing it from moving further. And it is difficult to remove such a "gift" from the wheels.
| When did company foundation: | 2018 |
| Had this company exported to Ukraine? | Yes |
| What Products did this company exported to Ukraine? | Egoza, Putanka |
| How many employees? | 820 |
| What is daily output of MZP (Putanka) / Low Visible Wire Barrier? | around 800 pcs |
| How many containers can export per Month? | 4-8 pcs |
| Is this company a factory? or trading company | Factory, but can export |
| What is the company's revenue? | CNY71,550,000 |
| Which seaport can export? | Qingdao, Tianjin, Ningbo etc |
| How many years did Cora work in this factory? | 7 years |
Mainly use 0.5 -0.9mm thinner steel wire, after weaving by hand, with 25 grands, 30 circles, to form a complex wire barrier. After unload, it is 3D mesh barrier, with a size 10m long, 10m width, and 1.1-1.4m height. Use pin and rings to install and fix.
| Open Size (M) | Weight (KG) with ps and rings |
|---|---|
| 10 x 10 x 1.1-1.4 | 30 -30.5 kg |
| 10 x 10 x 1.1-1.4 | 26.5 - 27 kg |
| 10 x 5 x 1.1-1.4 | 24.5 - 25 kg |
| Parameter | Meaning |
|---|---|
| Unfolded dimensions | 10x10x1.1-1.4 m |
| Wire diameter / number of garlands | 0.9 mm / 20 pieces 0.8 mm / 20 pieces 0.6 mm / 20 pieces 0.5 mm / 20 pieces twist - 0.8 mm |
| Folded dimensions | 1.2x0.6x0.8 m |
| Package weight without rings and peg | 29 kg |
| Complete set of the MZP package with rings and pegs | 40 rings + 40 pegs |
1/40HQ can load around 800 pcs of MZP(MPP) Low visibility wire.
MPP Plutanka is installed by 4-8 people on the ground, on a fence, on a building wall and on the roof of a building or structure.
In the lower tier there are garlands with a large diameter of wire.
The lower rings of the inconspicuous obstacle are attached to the ground with staples or other devices every 1-2 meters along the perimeter of the barrier.
The upper edge of the MPP Plutanka must be fixed on pegs to add volume and improve the barrier properties.
