商品の詳細:
お支払配送条件:
|
| 製品名: | ミル 1 折りたたみ軍事バリア亜鉛メッキセキュリティウォール洪水戦術砂充填バリア | 表面処理: | 溶融亜鉛メッキ |
|---|---|---|---|
| 仕様: | ミル 1 | Geotextileの色: | ミルタリーグリーン |
| ストック: | 1000個 | パッケージ: | プラスチックからパレットまで |
| 使用: | 洪水制御保持壁 | 名前: | ミル 1 折りたたみ軍事バリア亜鉛メッキセキュリティウォール洪水戦術砂充填バリア |
| ハイライト: | galvanized military folding barrier,sand-filled tactical security wall,flood protection military barrier |
||
Mil 1 Folding Military Barrier Galvanized Security Wall Flood Tactical Sand-Filled Barrier
Embassy and government building perimeter
Critical infrastructure protection (power plants, data centers)
Stadium and mass gathering security
| Parameter | Details |
|---|---|
| Material | PVC-coated polyester mesh + non-woven geotextile |
| Unfolded Size | 1800×1200×700 mm |
| Filled Weight | 1500–2000 kg |
| Empty Weight | 28 kg |
| Water Flow Resistance | Suitable for up to 1.5 m flood height |
| UV Resistance | ≥24 months direct exposure |
Quick Details
| Unit Type |
Height (M) |
Width (M) |
Length (M) |
Internal Cells |
| SX-01 | 1.37 | 1.08 | 10 | 9 |
| SX-02 | 0.61 | 0.61 | 1.22 | 2 |
| SX-03 | 1.0 | 1.0 | 10 | 10 |
| SX-04 | 1.0 | 1.5 | 6 | 6 |
| SX-05 | 0.61 | 0.61 | 3.05 | 5 |
| SX-06 | 1.68 | 0.61 | 3.05 | 5 |
| SX-07 | 2.21 | 2.13 | 8.25 | 4 |
| SX-08 | 1.37 | 1.22 | 10 | 9 |
| SX-09 | 1.0 | 0.76 | 6.84 | 9 |
| SX-10 | 2.13 | 1.52 | 7.6 | 5 |
Detail Specification
1. Wire diameter: 4-5mm
2. Mesh size: 75x75mm,50x50mm
3. Panel size: 12 type size for any security protection,suddenly burst attacks
4. Geotextile: in heavy duty non-woven polypropylene;
5. Color:Grey and Military Green,Sand color etc.
6. Finish: hot dipped galvanized, Galfan wire.
7. Packing: wrapped with shrink film or packed in pallet
| Material | Galvanized steel wire or zinc-aluminum alloy steel wire |
| Mesh Size | 50*50mm, 75*75mm, 76.2*76.2mm, 100*100mm, ect. |
| Wire Diameter | 4mm-6mm |
| Geotextile | 2mm thick, khaki/green, can vary according to different environments |
| Geotextile color | White, beige, Military Green and other customized colors |
|
|
Material: Galvanized steel wire or Galfan/ zinc-5%aluminum wire Service Life: 15-20 years Price:19.8$-99.8$/set Wire diameter: 3.0mm- 6.0mm Aperture:50*50mm 75*75mm 76.2*76.2mm 80*80mm 100*100mm etc Color of geotextile:Grey and Military Green,Sand color etc Gram Weight of geotextile:200g/m2 or 300g/m2 Finish:hot dipped galvanized,Galfan wire. Welded method:welded after galvanized or galvanized after welded Packing:Wrapped with shrink film then packed in wood pallet or iron pallet |
